稳二极管 1N5386B FD 长期供货 5386
- 产品价格：
- 面议/ 1pcs
- 交易说明：
- 本站所有价格仅供参考，网上订单需书面确认后生效，期盼您来函来电。
- 厂 家：
- FD
- 封 装：
- DO-35
- 批 号：
- 11+
- 数 量：
- 50000
产品咨询直线：021-38046966
产品详细说明
1N5386B
稳二极管 1N5386B FD 长期供货
| 功率特性：大功率 | 工作温度范围：125（℃） | 功耗：5W稳压管 |
| 型号：IN5386B | 材料：硅(Si) | 品牌：FD 飞达 |
| 产品类型：瞬变抑制二极管 | 是否进口：是 | 封装：DO-35 |
The 1N5333-5388B JEDEC registered series of axial-leaded 5.0 watt
Zeners provides voltage regulation in a selection from 3.3 to 200 volts with
different tolerances as identified by specific suffix letter on the part number.
These plastic encapsulated Zeners have moisture classification of Level 1
with no dry pack required and are also available in various military
equivalent screening levels by adding a prefix identifier as also described in
the Features section. They may be operated at high maximum dc currents
with adequate heat sinking with their comparatively low thermal resistance
design. Microsemi also offers numerous other Zener products to meet
higher and lower power applications.
JEDEC registered 1N5333 to 1N5388B
Zener voltage available 3.3V to 200V
Standard voltage tolerances are plus/minus 5%
with B suffix and 10 % with A suffix identification
Tight tolerances available in plus or minus 2% or
1% with C or D suffix respectively
Options for screening in accordance with MILPRF-
19500 for JAN, JANTX, JANTXV, and
JANS are available by adding MQ, MX, MV, or
MSP prefixes respectively to part numbers.
Surface mount equivalents available as
SMBJ5333 to SMBJ5388B, or SMBG5333B to
SMBG5388B
Regulates voltage over a broad operating current and
temperature range
Wide selection from 3.3 to 200 V
Flexible axial-lead mounting terminals
Nonsensitive to ESD per MIL-STD-750 Method 1020
Withstands high surge stresses
Minimal changes of voltage versus current as
specified by voltage regulation (ΔVZ)
High specified maximum current (IZM) when
adequately heat sunk
Moisture classification is Level 1 per IPC/JEDEC JSTD-
020B with no dry pack required
