供应AX1252，终端稳压器，AXELITE一级代理，AX1252深圳原装现货
产品详细说明
AX1252 1A Sink/Source Bus Termination Regulator with 1A LDO
性能描述：
The AX1252 is a 1A low dropout linear regulator with a high-speed linear regulator designed to generate termination voltage in double data rate (DDR) memory system to comply with the JEDEC SSTL_2 and SSTL_18 or other specific interfaces such as HSTL, SCSI-2 and SCSI-3 etc. devices requirements. The DDR regula tor is capable of actively sinking or sourcing up to 1A. The output termination voltage cab be tightly regulated to track 1/2VDD by two external vo ltage divider resistors or t he desired output voltage can be programmed by externally fo rcing the REFE N pin voltage.The AX1252 has an adjustable output LDO. The regulator output can be used to DDR input (VDD) this application is avoided two power input. The supply voltage is from 2.8V to 5.5V.
The AX1252 incorporates a high-speed differential amplifier to provide ultra-fast response in line/load transient. Other features include extreme ly low initial offset voltage, excellent load regulation, current limiting in and thermal shut-down protection. The AX1252 is available in the SOP8-EP (Ex posed Pad) surface mount package.
特点：
• DDR，DDR-II-I和DDR-III VTT应用的理想选择
• 每个通道1A连续电流LDO和DDR
• 集成功率驱动器
• 生成SSTL_2，终止电压为_18 SSTL，HSTL，SCSI-2，SCSI-3 接口。
• 高输出电压精度在满负荷
• DDR输出由两个外部电阻调整
• LDO可调输出由外部电阻器。
• 低外部元件数
• 独立的关断功能
• 电流限制和热关断保护
• SOP-8L和裸露焊盘的无铅封装。
