AX6636  Dual 600mA LDO Regulator with Enable Function

性能描述：

        The AX6636A/B/C is an efficient, precise dual-channel CMOS LDO regulator optimized for ultra-low-quiescent applications. Regulators output1 and output2 are capable of sourcing 600mA  of  output  current.  The  regulators  are  stable  with  output  capacitors as low as 1μF, including  current  limit,  thermal  shutdown  protection,  fast  transient  response,  low  dropout voltage, high output accuracy, current limiting protection, and high ripple rejection ratio. The AX6636A/B/C  contains  internal  pull  high  enable  function  that  allows  the  output  of  each regulator to be turned off independently. The AX6636A/B/C regulators are available in used SOP-8L with Exposed Pad package.
 特点：

典型应用电路图：
